Trek Marlin 5 Gen 3 2024

SKU: 5292509
Available in store: Check availability

Available in store

Close
C$929.99
Add to cart
3 in stock
  • Overview
  • Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail.

Product details

IN STORE PICKUP OR LOCAL DELIVERY ONLY

Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. It features a trail-savvy frame with a suspension fork, 9-speed Shimano CUES shifting, and mounts for a rack and kickstand that make it an ideal choice for trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike.





IT'S RIGHT FOR YOU IF

You're new to the trail and you’re looking for a real mountain bike that doubles as a commuter — and you want it all at an exceptional value.

THE TECH YOU GET

A lightweight aluminum frame with internal routing to protect your cables and add to the bike's sleek look, an upgraded 9-speed Shimano CUES drivetrain, a wide range of gearing so you always have the right gear for your terrain, powerful hydraulic disc brakes, and a terrain-smoothing suspension fork with a lockout.

THE FINAL WORD

Marlin 5 is a great ride for all your adventures. It's also versatile and a popular ride on college campuses because the rack and kickstand mounts make it easy to accessorize and haul a load.

WHY YOU'LL LOVE IT

Marlin Gen 3 gives you serious trail capability, with big tire clearance and slack, confidence-boosting geometry that keeps you stable from singletrack to city

Rack and fender mounts make it easy to accessorize, so your mountain bike can double as a rugged commuter

Its ThruSkew system is safer, simpler, and stronger, plus it makes removing the rear wheel easy for flat fixes in a pinch

Internal routing makes it easy to add a dropper post that lets you lower your saddle on the fly for more confident descending

Marlin models in sizes XXS and XS have a curved top tube and lower standover height that makes it easier for smaller riders to mount and dismount

SPECS



FRAMESET

*Frame: Size: XS
Alpha Silver Aluminum, curved top tube, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew

Size: S , M , ML , L , XL
Alpha Silver Aluminum, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew

*Fork: Size: XS
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5" wheel, 100mm QR, 80mm travel

Size: S
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel

Size: M , ML , L , XL
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29" wheel, 100mm QR, 100mm travel

Max Fork Compatible: 120mm, XXS: 80mm

WHEELS

Hub Front: Formula DC-20, alloy, 6-bolt, 5x100 mm QR

Hub Rear: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR

Skewer Rear: 173x5mm QR

*Rim: Size: XS , S
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve, Black

Size: M , ML , L , XL
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve

*Tire: Size: XS , S
Bontrager XT3 Comp, wire bead, 30 tpi, 27.5x2.40''

Size: M , ML , L , XL
Bontrager XT3 Comp, wire bead, 30 tpi, 29x2.40''

Max Tire Size: Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer

DRIVETRAIN

Shifter:Shimano U4000, 9 speed

Rear Derailleur: Shimano CUES U4000

*Crank: Size: XS
Prowheel C10Y-NW, 30T steel narrow-wide ring, 160mm length

Size: S , M , ML , L , XL
Prowheel C10Y-NW, 30T steel narrow-wide ring, 170 mm length

Cassette: Shimano LINKGLIDE LG300, 11-46, 9 speed

Chain: Shimano LG500

Pedal: VP-536 nylon platform

Max Chainring Size: 1x: 34T, 2x: 36/22

COMPONENTS

*Seatpost: Size: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm length

Size: ML , L , XL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length

*Handlebar: Size: XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width

Size: S
Bontrager alloy, 31.8mm, 15mm rise, 720mm width

Size: M , ML , L , XL
Bontrager alloy, 31.8mm, 15mm rise, 750mm width

Grips: Bontrager XR Trail Comp, nylon lock-on

*Stem: Size: XS , S
Bontrager Comp, 31.8mm, 7 degree, 35mm length

Size: M , ML , L
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length

Size: XL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length

Headset: Semi-integrated, 1-1/8"

Brake Rotor: Tektro, 6-bolt, 160mm

*Brake Set:  Size: XS , S
Tektro HD-M276 hydraulic disc, short reach

Size: M , ML , L , XL
Tektro HD-M275 hydraulic disc

Max brake rotor sizes - Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer
